VORTICE LINEO 100 T V0
CATEGORY: IN-LINE FANS
• Material: self-extinguishing plastic resin (self-extinguishing capability V0)
• Nominal diameter 100 mm.
• 2 speed AC motor with thermal overload cutout and shaft turning in ball bearings, coupled to mixed flow axial-centrifugal impeller.
• Minimum air flow 180 m3/h
• Maximum air flow: 285 m3/h
• Equipped with an electronic timer designed to shut off the motor automatically after a set interval, selectable during installation in the range 3’-20’ (default setting 3’).
• IMQ SAFETY a...
• Material: self-extinguishing plastic resin (self-extinguishing capability V0)
• Nominal diameter 100 mm.
• 2 speed AC motor with thermal overload cutout and shaft turning in ball bearings, coupled to mixed flow axial-centrifugal impeller.
• Minimum air flow 180 m3/h
• Maximum air flow: 285 m3/h
• Equipped with an electronic timer designed to shut off the motor automatically after a set interval, selectable during installation in the range 3’-20’ (default setting 3’).
• IMQ SAFETY and IMQ PERFORMANCE certifications
• Vortice speed controllers.
